Extension state information. More...
Data Fields | |
| struct ast_extension_state_device_snapshot * | device_snapshot |
| The current device snapshot for the extension. | |
| struct device_state_sources_vector | device_state_sources |
| Device state sources feeding the hint topic, and their forwarding. | |
| char | dialplan_context [AST_MAX_CONTEXT] |
| The dialplan context. | |
| char | dialplan_extension [AST_MAX_EXTENSION] |
| The dialplan extension. | |
| char | extension [0] |
| The combined extension this state is for (extension@context) | |
| struct stasis_forward * | extension_state_forwarder |
| Forwarder from per-extension topic to all topic. | |
| struct stasis_topic * | extension_state_topic |
| The extension state topic for this extension. | |
| struct ast_exten * | hint_extension |
| The dialplan hint that last configured this extension state. | |
| struct ast_extension_state_presence_snapshot * | presence_snapshot |
| The current presence snapshot for the extension. | |
| char * | presence_sources_string |
| The string representation of all presence state sources feeding this extension state. | |
Detailed Description
Extension state information.
Definition at line 98 of file extension_state.c.
Field Documentation
◆ device_snapshot
| struct ast_extension_state_device_snapshot* device_snapshot |
The current device snapshot for the extension.
Definition at line 100 of file extension_state.c.
Referenced by handle_show_hint().
◆ device_state_sources
| struct device_state_sources_vector device_state_sources |
Device state sources feeding the hint topic, and their forwarding.
Definition at line 108 of file extension_state.c.
◆ dialplan_context
| char dialplan_context[AST_MAX_CONTEXT] |
The dialplan context.
Definition at line 114 of file extension_state.c.
◆ dialplan_extension
| char dialplan_extension[AST_MAX_EXTENSION] |
The dialplan extension.
Definition at line 116 of file extension_state.c.
Referenced by complete_core_show_hint().
◆ extension
| char extension[0] |
The combined extension this state is for (extension@context)
Definition at line 118 of file extension_state.c.
Referenced by handle_show_hint().
◆ extension_state_forwarder
| struct stasis_forward* extension_state_forwarder |
Forwarder from per-extension topic to all topic.
Definition at line 106 of file extension_state.c.
◆ extension_state_topic
| struct stasis_topic* extension_state_topic |
The extension state topic for this extension.
Definition at line 104 of file extension_state.c.
Referenced by handle_show_hint().
◆ hint_extension
| struct ast_exten* hint_extension |
The dialplan hint that last configured this extension state.
Definition at line 112 of file extension_state.c.
Referenced by handle_show_hint().
◆ presence_snapshot
| struct ast_extension_state_presence_snapshot* presence_snapshot |
The current presence snapshot for the extension.
Definition at line 102 of file extension_state.c.
Referenced by handle_show_hint().
◆ presence_sources_string
| char* presence_sources_string |
The string representation of all presence state sources feeding this extension state.
Definition at line 110 of file extension_state.c.
The documentation for this struct was generated from the following file:
